iCure-4

iCure-4

PCB Curing Oven by Anda Automation (3 more products)

Note: Your request will be directed to Anda Automation

Product Specifications

Product Details

  • Part Number
    iCure-4
  • Manufacturer
    Anda Automation

General Parameters

  • Type
    IR Curing Oven
  • PCB Size
    50 - 460 mm
  • Operating Power
    18 kw
  • Power Consumption
    600W x 7 heat tubes at each zone
  • Power Supply
    3 Phase 380 VAC
  • Conveyor Direction
    Left to Right, Right to Left
  • Conveyor Height
    900 ± 20 mm
  • Conveyor Speed
    0.5 - 5 m/min.
  • Product Height
    ± 100 mm
  • Heating Time
    10 min
  • Exhausting Volume
    5 m3/min
  • Maximum Loading
    4 kg/m
  • Temperature Control Accuracy
    ± 5 Degree C
  • Temperature Scope IR Tube
    Room temp to 100 Degree C
  • Net Weight
    1000 kg
  • Overall Dimensions
    4000 x 1070 x 1300 mm
