51N

The 51N from Arlon EMD is a PCB Laminates with Df 0.02, Tg 170 to 368 Degree C, Frequency 0.1 GHz. More details for 51N can be seen below.

Product Specifications

Product Details

  • Part Number
    51N
  • Manufacturer
    Arlon EMD

General Parameters

  • Df
    0.02
  • Tg
    170 to 368 Degree C
  • Frequency
    0.1 GHz
  • Lead Free
    yes
  • Cte xy
    15 ppm/Degree C
  • Cte z
    44, 245 ppm/Degree C
  • RoHS
    Yes
  • Electrical strength
    1000 (39.4) kV/mm (V/mil)
  • Flamibility
    Meet V0 class
  • Material
    FR-4
  • Peel strength
    6.7 (1.2), 6.4 (1.1) N/mm (lb/inch)
  • Poissons ratio
    6.5 (45)
  • Surface resistivity
    2.9 x 10^7, 4.0 10^6 Mohm
  • Thermal conductivity
    0.25 W/mK
  • Volume resistivity
    2.6 x 10^7,3.3 10^7 Mohm-cm
  • Water absorption
    0.001
  • Youngs modulus
    2.6 (18) Mpsi (Gpa)
