GA-LD

The GA-LD from GRACE ELECTRON is a PCB Laminates with Td 340 to 355 Degree C, Frequency 0.1 to 15 GHz. More details for GA-LD can be seen below.

Product Specifications

Product Details

  • Part Number
    GA-LD
  • Manufacturer
    GRACE ELECTRON

General Parameters

  • Type
    Halogen-free
  • Td
    340 to 355 Degree C
  • Frequency
    0.1 to 15 GHz
  • UL
    yes
  • Lead Free
    yes
  • Halogen Free
    yes
  • Arc resistance
    120 Sec
  • Cte xy
    13, 15 ppm/Degree C
  • Cte z
    45, 220 ppm/Degree C
  • Dielectric breakdown
    40 kV
  • Electrical strength
    40 KV/mm
  • Flamibility
    UL94 V-0
  • Flexural strength
    450, 400 N/mm2
  • Industry application
    Automotive, Energy
  • Material
    FR-4
  • Moisture absorbtion
    0.001
  • Peel strength
    5.5(0.96) Lb/in(N/mm)
  • Size
    1244×0940, 1244×1042, 1244×1093
  • Surface resistivity
    2.0 x 10^8
  • Thermal conductivity
    0.40 W/m･K
  • Thickness inches
    0.002 to 0.125
  • Thickness mm
    0.05 to 3.2 mm
  • Volume resistivity
    7 x 10^9
