G-W2

G-W2

Wave Soldering Equipment by GUS (2 more products)
Download Brochure Request Quote

Note: Your request will be directed to GUS

The G-W2 from GUS is a Wave Soldering Equipment with Wave Height 0 to 12 mm. More details for G-W2 can be seen below.

Product Specifications

Product Details

  • Part Number
    G-W2
  • Manufacturer
    GUS

General Parameters

  • Wave
    Dual Wave
  • Wave Height
    0 to 12 mm
  • Preheat Zones
    3 Zones
  • PCB Size
    50 to 250 mm
  • PCB Direction
    Left to Right, Right to Left
  • Conveyor Angle
    4 to 6 Degree
  • Conveyor Speed
    300 to 1200 mm/min
  • Flux Volume
    6 litres
  • General Power
    15 kW
  • Preheat Power
    6 kW
  • Running Power
    3.5 kW
  • Power Supply
    3P AC380V 50 Hz 63A
  • Controlling System
    PLC Key +PLC
  • Max Preheat 1 Temp
    Room Temp - 250 Degree C
  • Net Weight
    800 kg
  • Overall Dimensions
    2600 x 1200 x 1700 mm
