KD-V400

Reflow Soldering Equipment by Beijing Chengliankaida Technology Co, Ltd (15 more products)
Download Brochure Request Quote

Note: Your request will be directed to Beijing Chengliankaida Technology Co, Ltd

The KD-V400 from Beijing Chengliankaida Technology Co, Ltd is a Reflow Soldering Equipment with Heating Zone Length 280 mm. More details for KD-V400 can be seen below.

Product Specifications

Product Details

  • Part Number
    KD-V400
  • Manufacturer
    Beijing Chengliankaida Technology Co, Ltd
  • Description
    Inline Vacuum soldering systems

General Parameters

  • Reflow Oven Type
    Inline Reflow Oven
  • Heating Technology
    IR Heating
  • Temp Range
    300 Degree C
  • Temp Accuracy
    1 Degree C
  • Heating Zones
    2 Zones
  • Heating Zone Length
    280 mm
  • Conveyor Height
    950 ± 20 mm
  • Control Type
    Siemens PLC1200 Control System
  • Process Features
    Vacuum Reflow Support, Nitrogen Atmosphere Support
  • Power Supply
    380V, 50/60 Hz,3-Phase
  • General Power
    35 kW
  • Power Consumption
    12 to 15 kW
  • Overall Dimensions
    3950 x 1960 x 1900 mm
  • Net Weight
    2900 kg
