New White Papers & Articles

Latest Trends in Core Materials Supporting Next-Generation Semiconductor Packages and Substrate - Resonac Corporation

PDN Basics for the PCB Designer - Altium Limited

Assembling High Current Heavy Copper PCBs - Advanced Assembly

A Guide To Component Placement by Michael Keens - Texcel Technology PLC

THR: Through hole technology for the reflow oven - SCHURTER AG

5 Tips for Specifying PCB Hole Size Tolerance - Altium Limited

More Whitepapers

New PCB Equipments

3D Automated X-ray Inspection Machine for PCBs up to 1000 x 660 mm

X-ray Inspection System from Test Research, Inc

The TR7600 SV from Test Research, Inc. (TRI) is a 3D Automated X-ray Inspection (AXI) Machine. It has a resolution of up to 7 µm, can precisely detect void defects and delivers high-yield-rate inspection. This AXI machine supports PCB dimensions up to 1000 x 660 mm with a thickness from 0.4 to 7 mm and a maximum PCB weight of 12 Kg.

Download Brochure Product Details

Single-Zone, 120°C Rotary Indexing Vertical Curing Oven

PCB Curing Oven from PVA Global

The RIVO from PVA Global is a Convection Curing Oven with one heating zone with a temperature of up to 120°C. It is a vertical solution for substrates requiring extended curing times in a design that is footprint-friendly. This oven has a rotary carousel fed by a motorized lift that stacks substrates vertically and gives the end-user flexibility in specifying rack pitch and quantity.

Download Brochure Product Details

Optical 3D Inspection System with Dual Track Operation

Automated Optical Inspection (AOI) Equipment from Viscom AG

The S3088 DT from Viscom is an Automated Optical Inspection (AOI) Equipment for PCB dimensions of up to 450 mm x 350 mm and minimum width of 70 mm. It has an inspection speed of up to 65 sq. cm./s and a field of view of 50 x 50 mm. The system has eight angled-view cameras with switchable orthogonal resolution (10 µm) and can reliably inspect 03015 components for solder joints, placement, and solder paste.

Download Brochure Product Details

PCB Prototyping Equipment with Automatic Tool Change

PCB Prototyping Equipment from MITS Electronics

The Auto Lab from MITS Electronics is a PCB Prototyping Equipment with support for automatic tool change. It has a working area of 229 x 300 x 45 mm and allows up to 10 automatic tool changes. This equipment has a spindle speed of 62,000 RPM and includes a stepper motor with support for the X, Y, and Z control axes. It has a travel speed of up to 55 mm/sec and a resolution of 0.156 µm.

Download Brochure Product Details

105,000 CPH Pick-and-Place Machine for PCBs up to 810 x 500 mm

Pick and Place Machine from Juki Americas

The LX-8 from Juki Americas is a Pick-and-Place Machine that supports PCBs measuring up to 810 x 500 mm. It uses two P20S 20 nozzle planet heads to reach speeds of up to 105,000 CPH with an accuracy rate of ±40 µm. This machine allows users to choose between the P20 rotary planet head and the Takumi Head with adjustable head height for precise placement.

Download Brochure Product Details

High-speed Dispenser for PCBs up to 510 x 460 mm

Dispenser from Yamaha Motor Co., Ltd

The YSD from Yamaha Motor is a Dispenser that supports PCB dimensions from 50 x 50 mm to 510 x 460 mm. It allows users to select from 2 heads (standard) or 3 heads (option) to match the production format. This dispenser supports a full-universal type high accuracy dispense head that gives independent Z-axis and R-axis servo control while supporting multi-fluid, multi-state liquid dispensing.

Download Brochure Product Details

Stencil Printer with Integrated 3D SPI

Solder Paste Printer from Kurtz Ersa

The VERSAPRINT 2 ULTRA³ from Kurtz Ersa is a Stencil Printer with fully integrated 3D SPI. It has a printing size of 680 x 500 mm and two independent squeegee heads with continuous squeegee force control, squeegee depth stop, and pendulum limitation. This printer has a print speed of up to 200 mm/s and has a print accuracy of ± 25 µm @ 6 Sigma (CPR > 2). The integrated 3D-SPI enables this printer to inspect complex PCBs directly after the printing process and can detect errors before they appear.

Download Brochure Product Details

Sponsored by Digi-Key

Solder Paste Printer for PCBs up to 350 x 300 mm

Solder Paste Printer from Panasonic Corporation

The SPV-DC from Panasonic Corporation is a Solder Paste Printer that supports PCB dimensions from 50 x 50 mm to 350 x 300 mm. It has a PCB exchange time of 13.0 seconds including transfer, positioning, recognition and each time cleaning (for a PCB measuring 250 x 165 mm). This printer enables compact dual-lane production with front/rear independence to provide a production line that matches customer production needs.

Download Brochure Product Details

Automatic PCB Magazine Unloader for SMT Production Lines

Loader/Unloader from Winson automatic equipment Limited

The UL-250E-MTC from Winson Automatic Equipment is an Automatic PCB Magazine Unloader for surface-mount (SMT) production lines. It supports PCBs with dimensions from 50 x 50 to 350 x 250 mm and has a magazine size of 350 x 320 x 563 mm. This unloader has a transport direction from Left to Right and has a transport height of 950 mm.

Download Brochure Product Details

Low-Cost X-ray Inspection System with Inspection Area of 430 x 430 mm

X-ray Inspection System from VJ Electronix

The Apogee 90 from VJ Electronix is an X-ray Inspection System. It is an affordable and reliable inspection system with advanced features for defect detection, failure analysis, and NDT in production environments. This system is capable of capturing clear 2D & 2.5D X-ray images that provide operators with confidence in their findings.

Download Brochure Product Details

High-Speed Pick and Place Machine for PCBs up to 640 x 510 mm

Pick and Place Machine from Mycronic AB

The MY300DX from Mycronic is a pick-and-pace machine featuring up to 224 feeder positions with a top speed of 40,000 components per hour (CPH). This machine is suitable for PCB sizes ranging from 70 x 50 mm to 640 x 510 mm and board thickness from 0.4 to 6.0 mm. It conforms to SMEMA standard for board transfer height, with board height adjustable from 880 to 975 mm.

Download Brochure Product Details

Hand Door Conveyor for PCB Size up to 530 x 460 mm

PCB Conveyor from Shenzhen Gosmt Technology Co.,Ltd

The GC-460W-N from Shenzhen Gosmt Technology is a Hand Door Conveyor. It supports PCB dimensions from 50 x 50 mm to 530 x 460 mm with transport direction from left to right or right to left. This flat-belt conveyor has a speed of up to 20 m/min (can be customized) and supports smooth width adjustments using a screw shaft.

Download Brochure Product Details

136,000 CPH Pick and Place Machine for PCB Sizes up to 330 x 250 mm

Pick and Place Machine from Yamaha Motor Co., Ltd

The S-F8S Single from Yamaha Motor is a Pick and Place Machine that supports PCB dimensions from 50 x 50 mm to 330 x 250 mm. It supports up to 80 component types and has a mounting speed of 136,000 CPH with a mounting accuracy of ±25µm. This machine is available in an enclosure that measures 1280 x 2240 x 1450 mm and requires a 3-phase AC supply.

Download Brochure Product Details

Fully-Automated Solder Paste Printer for PCB Sizes up to 450 x 350 mm

Solder Paste Printer from ITW EAE

The Edison II ACT from ITW EAE is a Solder Paste Printer that supports PCB dimensions from 50 x 50 mm to 450 x 350 mm. It has integrated automated changeover technology that is fast and consistent with reduced operator requirements, which results in error-free changeover and increased yield and throughput.

Download Brochure Product Details
