KTR-1000D

Reflow Soldering Equipment by Shenzhen Kait High-Tech Co.,Ltd (16 more products)
Download Brochure Request Quote

Note: Your request will be directed to Shenzhen Kait High-Tech Co.,Ltd

The KTR-1000D from Shenzhen Kait High-Tech Co.,Ltd is a Reflow Soldering Equipment with Heating Zone Length 3892 mm, Max Pcb Width 50 to 300 mm. More details for KTR-1000D can be seen below.

Product Specifications

Product Details

  • Part Number
    KTR-1000D
  • Manufacturer
    Shenzhen Kait High-Tech Co.,Ltd
  • Description
    Dual Lane Reflow Oven

General Parameters

  • Cooling Zones
    3 Zones
  • Heating Zones
    10 Zones
  • Heating Zone Length
    3892 mm
  • Max Pcb Width
    50 to 300 mm
  • Component Height
    Top - 25 mm, Bottom - 25 mm
  • Control Type
    Industrial, Computer, PLC+ Modular＋PID
  • Conveyor System Type
    Rail, Chain Conveyor
  • Conveyor Direction
    Left to Right
  • Conveyor Height
    920 ± 20 mm
  • Conveyor Speed
    300 to 2000 mm/min
  • Conveyor Type
    Rail + Chain
  • Cooling Method
    Forced Air Cooling
  • Exhausting Flow Per Port
    10 m2/h
  • General Power
    83 kW (Total Power)
  • Power Consumption
    11 kW
  • Power Supply
    3P 380 V/220 V 50/60 HZ
  • Startup power
    38 kW
  • Temp Accuracy
    ±1 Degree C
  • Process Features
    Lead-Free Soldering Support
  • Reflow Oven Type
    Inline Reflow Oven
  • Temp Range
    300 Degree C
  • Temperature control precision
    PID + SSR
  • Temperature deviation on PCB
    ± 1.5 Degree C
  • Net Weight
    3060 kg
  • Overall Dimensions
    6300 x 1680 x 1530 mm
