QH320

Reflow Soldering Equipment by Yueqing Qihe Electronic Technology Co.,Ltd (8 more products)
Download Brochure Request Quote

Note: Your request will be directed to Yueqing Qihe Electronic Technology Co.,Ltd

The QH320 from Yueqing Qihe Electronic Technology Co.,Ltd is a Reflow Soldering Equipment with Heating Zone Length 960 mm, Max Pcb Width 300 mm. More details for QH320 can be seen below.

Product Specifications

Product Details

  • Part Number
    QH320
  • Manufacturer
    Yueqing Qihe Electronic Technology Co.,Ltd
  • Description
    QRF320 / QH320 Crawler-type 5 Zones SMT Reflow Oven solder welding

General Parameters

  • Reflow Oven Type
    Desktop Reflow Oven
  • Heat Type
    Intelligent level sirocco and rapid infrared heating
  • Heating Technology
    IR Heating
  • Temp Range
    350 Degree C
  • Temp Accuracy
    ± 3 Degree C
  • Temperature deviation on PCB
    ± 2 Degree C
  • Heating Zones
    5 Zones
  • Heating Zone Length
    960 mm
  • Cooling Zones
    1 Zone
  • Conveyor System Type
    Chain Conveyor
  • Conveyor Direction
    Left to Right
  • Conveyor Speed
    0 to 1600 mm/min
  • Max Pcb Width
    300 mm
  • Power Supply
    Three phase 5 line 380 V 50/60 Hz
  • General Power
    4.5 kW
  • Overall Dimensions
    1450 x 630 x 470 mm
  • Net Weight
    90 kg
