SHS 60L

Solder Paste Inspection Equipment by GSUNG SYSTEM Co., Ltd (1 more product)

Note: Your request will be directed to GSUNG SYSTEM Co., Ltd

SHS 60L

Product Specifications

Product Details

  • Part Number
    SHS 60L
  • Manufacturer
    GSUNG SYSTEM Co., Ltd

General Parameters

  • Field of View
    20 x 20 mm
  • Defects
    Height, Offset, Bridge
  • PCB Size
    550 x 510 mm
  • PCB Thickness
    0.4 to 4 mm
  • PCB Weight
    1.3 kg
  • Imaging Speed
    60 sq. cm/sec
  • Height Resolution
    1000 ㎛
  • Camera
    18 x 18 ㎛ pixel resolution
  • 3D Technology
    Yes
  • Top Clearance
    15 mm
  • Bottom Clearance
    25 mm
  • Edge Clearance
    2.5 mm, 3 mm
  • Net Weight
    1000 kg
  • Overall Dimensions
    1060 x 1285 x 1450 mm
