E-TekNet was started up in 2001 and incorporated in Arizona USA. E-TekNet is a complete resource for PCB and PCBA (PCB assembly) including: Bare board PCB manufacturing, PCB reverse engineering, solder stencil, PCB assembly and functional test from prototypes to mass production. E-TekNet Headquarters is located in Chandler, Arizona, USA, with 100% owned two manufacturing factories in China. Unlike most of competitors in the market, We are not a broker or middleman. Therefore, we control the quality and on-time shipping directly without overhead cost from middleman. You order from a USA company with low manufacture cost.
Loading additional locations...
E-TekNet has many professional PCB design customers who specialize in all kinds of engineering design work. From the simple layout if you have your own schematics or drawings to the most difficult reverse engineering or complete product design support.
