New and Interesting Equipment

3D AOI Equipment using Laser-Based 3D Imaging Technology

Automated Optical Inspection (AOI) Equipment from PARMI

The Xceed from PARMI is a 3D AOI Equipment that is designed for in-line inspection of PCB assemblies using a laser line scan method. It combines simultaneous 2D and true 3D measurement to capture dimensional and surface data in a single scan, enabling accurate detection of defects such as misalignment, missing components, solder joint issues, and coplanarity errors.

Download Brochure Product Details

2D, 2.5D, and 3D Offline X-ray Inspection Equipment

X-ray Inspection Equipment from Creative Electron Inc

The TruView™ Novus from Creative Electron Inc. is an X-ray Inspection Equipment that is designed for offline 2D, 2.5D, and 3D inspection of PCBs. It has a sealed X-ray tube with an adjustable output voltage of 40-130 kV, an output power of up to 65 W, and a 5µm focal spot size for exceptional clarity. This equipment has a flat-panel detector (FPD) with a pixel size of 84 µm, an inspection area of 129 x 129 mm, and provides 1600x magnification & a frame rate of up to 20 fps.

Download Brochure Product Details

PCB Depaneling Equipment with Dual V-Shaped Blades for Cutting

Depaneling Equipment from Fancort Industries, Inc

The VPD5-330 from Fancort Industries is a PCB Depaneling Equipment that uses dual "V" Shape blades for a perfect board cut without bending or tension. It has a heavy frame for stability, pneumatic cylinder operated. This equipment supports PCBs of length up to 14 inches & can separate panels 0.024 to 0.100 inches in thickness and shears boards safely with parts as close as 0.020 inches to the score line, including ceramic capacitors.

Download Brochure Product Details

Selective Soldering Machine with Mini-Solder Wave Technology

Selective Soldering Machine from TM Soldering Solutions

The PHOENIX-IL from TM Soldering Solutions is a Selective Soldering Machine that uses mini-solder wave technology to deliver exceptional performance and consistency. It performs the soldering process by holding the PCB stationary while a high-precision XYZ axis mechanism executes the flux and soldering procedures with exceptional accuracy.

Download Brochure Product Details

Soldering Station Based on Chip-in-Cartridge Technology

Soldering Station from Metcal

The GT90-HP-T4 from Metcal is a Soldering Station that is based on patented chip-in-cartridge technology. It has an adjustable soldering temperature range from 200 to 450 °C and programmable standby/sleep settings. This soldering station has a 2.5” display and a USB port to power accessories. It requires an AC supply of 100-240 V and consumes 90 W of power. This soldering station measures 11.0 x 12.5 x 16 cm.

Download Brochure Product Details

Sponsored by ICPA Expo 2026

ICPA Expo 2026 – India’s Premier Electronics & PCB Industry Expo

Join India’s premier electronics and PCB industry expo to connect with top manufacturers, suppliers, and buyers. Showcase your innovations, expand your network, and generate high-quality business leads to accelerate growth. Click here to learn more.

Reflow Soldering Oven with 8, 10, or 12 Heating Zones

Reflow Soldering Equipment from ETS Energy Technology Systems, Inc

The ETSMax Series from ETS Energy Technology Systems, Inc., are Reflow Soldering Ovens that have 8, 10, or 12 heating zones (top & bottom). They have a heating zone length of 3121, 3891, or 4706 mm and a cooling zone length of 800 mm. These ovens use convection (RHA) heating and can handle PCBs of width up to 460 mm. They have a PCB counter, a PCB dropping alarm, and a flux chiller (N2 ovens).

Download Brochure Product Details

In-Line PCB Cleaning Machine with Drying Capabilities

PCB Cleaning Machine from ITW EAE

The Aquastorm 200 from ITW EAE is an In-Line PCB Cleaning Machine designed to provide advanced cleaning and drying capabilities in a single, compact cleaning platform. It can accommodate PCB widths of up to 508 mm (optional 610 mm). This machine uses proprietary pump and nozzle technology throughout the system to optimize performance and has appropriately sized modules and strategic manifold placement to increase throughput while ensuring thorough removal of contaminants.

Download Brochure Product Details

3D AOI Equipment for Automotive Electronics

Automated Optical Inspection (AOI) Equipment from MIRTEC

The GENESYS-AUTO from MIRTEC is a 3D AOI Equipment that is specially designed for automotive electronics. It has a 12 MP camera with 10µm/15µm high-resolution lenses for greater precision and stability in inspection, and additionally uses a CoaXPress interface to enable high-speed inspection. This equipment also has four 18 MP side cameras that enable side-view OCR inspection and solder inspection of J-leads, coils, and QFNs, which are challenging to inspect from a top-down perspective.

Download Brochure Product Details

Depaneling Equipment for V-Scored Small-Sized PCBs

Depaneling Equipment from FKN SYSTEK, INC

The K2010 from FKN Systek is a Depaneling Equipment that is designed for singulating V-scored PCBs consistently. It uses dual 2.5-inch diameter circular blades to separate boards, helping maintain cut accuracy while minimizing the risk of damage caused by manual handling fatigue. The panels are guided through adjustable front and rear rails, ensuring proper alignment before entering the cutting area.

Download Brochure Product Details

Inline SMT Line Loader for PCB sizes up to 600 x 510 mm

Loader/Unloader from Inline SMT

The GMLD-510A-600 from Inline SMT is an Inline SMT Line Loader that is designed for loading both populated and unpopulated printed circuit boards into the manufacturing line. It can handle PCB sizes from 50 x 150 mm to 600 x 510 mm and PCB thicknesses ranging from 0.6 mm to 6 mm. This loader has a capacity of 23 boards and a cycle time of 6 seconds. It requires an AC supply of 120 V and has a footprint of 44 x 60 x 60 inches.

Download Brochure Product Details
