New PCB Equipment

25000 DPH Liquid Dispenser for High-Speed Dispensing

Dispenser from PPM, Inc

The Camalot 5000 from PPM is a high-speed Adhesive or Solder Paste Dispenser for applications involving large boards or multi-up panels. It has a dispensing area of 450 x 450 mm and the dispenser nozzle moves at a speed of about 250mm/s or 10 IPS. The dispensing of the equipment is of standard time/pressure method with a dispensing rate of 25000 dots per hour, ensuring a fast and efficient assembly process. It uses a 25 microns camera that produces high-resolution images that make it easy for dispensing adhesives accurately.

Download Brochure Product Details

833 L, 1% RH Dry Cabinet with Five Adjustable Shelves

Dry Cabinet from SMT Dry Boxes

The T60M 1200 from SMT Dry Boxes is a Dry Cabinet that is designed for the storage and restoration of moisture-sensitive devices (MSDs). It successfully achieves humidity levels below 1% RH (Relative Humidity) making it an optimal choice for drying applications in electronics. The cabinet has internal dimensions measuring 1140 x 490 x 1450 mm and has a total capacity of 833 liters. These cabinets preserve SMT components, component reels, SMDs, PCBs, precision metal parts, miniature devices, pharmaceutical substances, and more.

Download Brochure Product Details

RoHS-Compatible Water-Soluble Fine Pitch Solder Paste

Solder Paste from MacDermid Alpha Electronics Solutions

The ALPHA WS-699CPS from MacDermid Alpha Electronics Solutions is a Water-Soluble Fine Pitch Solder Paste. It is RoHS-compatible and has a chemical composition of an alloy of Tin, Silver, and Copper (SnAgCu) that comprise about 0.89% of the total solder paste composition. The composition of the alloy is Sn (96.5%), Ag (3%), and Cu (0.5%), and has an average melting temperature range from 217 to 220°C. It is capable of 50 µm aperture printing performance with low voiding and excellent soldering and residue cleaning performance, and can be packaged in the form of a Cartridge, and Jar.

Download Brochure Product Details

Solder Paste Inspection Equipment for PCB Dimensions up to 350 x 533 mm

Solder Paste Inspection Equipment from Mycronic AB

The PI PICO from Mycronic is a Solder Paste Inspection Equipment. It features an 80 MP, 12-bit CMOS camera sensor to capture intricate details and has an imaging speed of 3 seconds per FOV. This machine has an inspection camera POV from 1160 x 55 mm to 350 x 55 mm, ensuring an adjustable and wide-phase inspection. The system can accommodate PCBs with dimensions ranging from 51 x 51 mm to 350 x 533 mm with a PCB thickness from 0.1 to 7.5mm. The conveying height ranges from 830mm to 930mm (standard) or 900mm to 1,000mm (optional).

Download Brochure Product Details

Reflow Soldering Machine 14 Heating/Cooling Zones

Reflow Soldering Equipment from ITW EAE

The CT+1040 from ITW EAE is a Reflow Soldering Machine for heavy solder paste users. It has 4 cooling zones and 10 heating zones with a zone length of 3550 mm (about 11.65 ft) and both zones provide ample space for cooling and heating the solder material. This soldering machine uses Fast Cool Down (FCD) method that effectively dissipates heat and ensures efficient temperature reduction. It allows the conveyor speed to be adjusted from 25 to 200 cm/min, providing flexibility to match the production requirements, and can accommodate PCBs up to a maximum dimension of 300 x 300 mm.

Download Brochure Product Details

X-Ray Inspection System for PCB Dimensions up to 1205 x 672 mm

X-ray Inspection System from Nordson Corporation

The XD7800NT Ruby XL from Nordson Corporation is an X-ray Inspection System that can inspect Printed Circuit Boards of varied sizes. It can accommodate a maximum PCB size of 1205 x 672 mm with reduced magnification and allows an area of 96 x 67 cm to be inspected non-destructively. This system uses a 3-megapixel camera, having a focal spot range between 0.5 to 0.95 µm, resulting in high-quality images. It can be operated via a Joystick control (X, Y or X, Y & Z) that enables a complete 360° view around a point of interest, by its 70° oblique angle views (over 762 x 610 mm).

Download Brochure Product Details

Sponsored by Digi-Key

In-Circuit Tester with Auto-Calibration for PCB Dimensions up to 600 x 350 mm

In-Circuit Tester from Test Research, Inc

The TR5001E SII from Test Research, Inc is an In-Circuit Tester (ICT) for PCBs measuring up to 600 x 350 mm. It offers comprehensive testing capabilities by consolidating MDA, ICT, and FCT functionalities into a single platform, streamlining production lines, and reducing costs. This tester has 3456 test points with standard testing components including analog test hardware such as a 6-wire measurement switching matrix, programmable AC/DC/DC high voltage and current sources, AC/DC voltage, DC current measurement, and component R/L/C measurement.

Download Brochure Product Details

IR PCB Curing Oven for PCB Width up of 460 mm

PCB Curing Oven from Anda Automation

The iCure-2 from Anda Automation is an IR Curing Oven for PCB dimensions up to 460 mm in width. It has a power-efficient design that incorporates 7 heat tubes per zone, consuming only 600 W each. This oven has an adjustable conveyor speed from 0.5 to 5 m/min and supports conveyor directions from left to right with a conveyor height of 900 (±20) mm. With a swift heating time of 10 minutes and an exhausting volume of 5 m³/min, the equipment streamlines the workflow. It has a robust maximum loading capacity of 4 kg/m and offers a precision temperature control accuracy of ±5°C.

Download Brochure Product Details

PCB Flipper and Invertor with Working Width from 50 mm to 500 mm

PCB Flipper and Inverter from PVA Global

The BI2000 from PVA Global is a PCB Flipper and Inverter that can accommodate Printed Circuit Board sizes from 50 mm to 500 mm. The conveyor direction moves from both left to right and right to left, allowing ease of operation, while the conveyor height ranges from 890 to 965 mm. This system can accommodate a maximum pallet weight of 10 lbs and operates within a versatile conveyor speed range of 0.15 m/min to 24 m/min. It has the component clearance set at 100 mm (4 in) top and bottom, with an additional 4.75 mm (0.187 in) allowance for edge carrying (SMEMA).

Download Brochure Product Details

Selective Soldering Machine for Thru-Hole Soldering

Selective Soldering Machine from Kurtz Ersa

The VERSAFLOW ONE from Kurtz Ersa is Selective Soldering Machine that is ideal for thru-hole soldering where reflow and wave soldering methods seem inefficient. It has a solder pot capacity of 13kg and can accommodate PCBs weighing up to 8 Kg, ensuring that the device is useful for a wide range of PCB sizes. The equipment can store a total of 1.8 liters of flux and has a flux depositing accuracy of ±0.25 mm, which is deposited with a positioning speed of up to 200 mm/s. For solder printing, it has a position accuracy of +/-0.25 mm, with a position speed of up to 100 mm/sec.

Download Brochure Product Details

Fully Automatic Solder Paste Screen Printer for PCBs up to 850 x 600 mm

Solder Paste Printer from Shenzhen HC Automation Equipment Co.,Ltd

The HC-850 from Shenzhen HC Automation Equipment is a Solder Paste Printer that can accommodate Printed Circuit Boards ranging from size 80 x 50 mm to 850 x 600 mm. It has a printing alignment accuracy of ±0.02 mm to ensure a near-perfect placement of soldering material. This printer is equipped with 2 printing heads and provides a repeat accuracy of ±0.01 mm. It can accommodate substrates with a thickness ranging from 0.2 to 6 mm. The printer has a 16-second throughput, including print and stencil cleaning cycles, a changeover time of 2 minutes, and a new product setup time of 5 minutes.

Download Brochure Product Details
