Latest News & White Papers this Month

14th May, 2024 Newsletter - PCB Directory

Top stories this month. View it in your browser

Monthly Edition
Date: 14th May, 2024

Sponsored by DigiKey

Lynx™ Low-Profile Connectors

Lynx™ connector is a flexible 0.6mm pitch solution designed for high speed and high-density differential or single-ended signaling board-to-board applications. This connector provides designers with a readily available 85O solution. Click here to learn more.

New White Papers & Articles

Dispelling The Black Magic Of Solder Paste - FCT Solder

Halogen Free Base Materials for PWB Applications - Isola Group

Cleaning and No-Clean Process Control using the SIR Test Method and Electrical Twin - Spartronics

Advancement Of Solder Paste Inspection (SPI) Tools To Support Industry 4.0 & Package Scaling - Circuit Insight

More Whitepapers

Upcoming Event

PCB EAST 2024

Date: June 4-7, 2024

Location: Boxboro Regency Hotel and Conference Center, Boxborough, MA 01719

Manufacturing World 2024 Tokyo

Date: Jun, 19 - 21, 2024

Location: Tokyo Big Sight

More Events

Featured PCB Equipment

Pick and Place Machine for PCB Dimensions of 600 x 300 mm

Pick and Place Machine from Autotronik SMT-GmbH

The MAS 399 Pro from Autotronik SMT-GmbH is a Pick and Place Machine with two heads. The machine operates automatically and with a working vision system. It can accommodate Printed Circuit Boards of size 600 x 300mm, while the largest component size can be 5 x 5 mm. This machine has a placement rate between 1001 to 5000 cph.

Download Brochure Product Details

Inline Selective Soldering Machine for PCBs of size 350 x 450 mm

Selective Soldering Machine from Sasinno

The Unit-i1 from Sasinno is an Inline Selective Soldering Machine that can operate on PCBs of size 350 x 450 mm, with an optimal PCB weight of 5 kg. It includes a drop jet fluxer and bottom IR preheating, along with one solder pot featuring a wave tunnel. The PCB is transported via a conveyor, with the conveyor table capable of movement in the X/Y axes, while the solder pot/fluxer moves in the Z-axis.

Download Brochure Product Details

3D AOI Equipment for PCB Dimensions up to 533 x 609 mm

Automated Optical Inspection (AOI) Equipment from Mycronic AB

The MYPro I50 from Mycronic AB is an Automated Optical Inspection (AOI) Equipment. It is designed for inspecting PCBs of sizes from 51 x 51 mm to 533 x 609 mm with a thickness from 0.5 to 4 mm and weighing up to 3 kg. The camera has a field of view of 61.1 x 44.9 mm that produces images of resolution 4.75 µm, with a positioning accuracy of 0.1 µm.

Download Brochure Product Details

In-Line Flying Probe Tester for PCB Dimensions up to 890 x 483 mm

Flying Probe Tester from Takaya Corp.

The APT-1400F-A from Takaya Corp. is an In-Line Flying Probe Tester. It is a dual-sided testing equipment with 4 heads and can accommodate PCB sizes of up to 890 x 483 mm with thickness between 0.6 and 5 mm. This tester uses an automated conveyor that is supported by an AC power source of 200-240V single phase 50/60 Hz.

Download Brochure Product Details

High Accuracy and Flexible Conformal Coating Machine

Conformal Coating Machine from Specialty Coating Systems Inc

The PrecisionCoat BT from Specialty Coating Systems (SCS) is a Conformal Coating Machine. It applies materials via configurable conformal coating and/or dispense valves (up to two) that move along three axes (X, Y, and Z) with a command accuracy of ±0.003 mm. The dispenser supports substrate size from 3.81 x 5.08 cm to 30 x 35.6 cm (2 valves).

Download Brochure Product Details

Pick-and-Place Machine for Board Dimensions up to 630 x 508 mm

Pick and Place Machine from Universal Instruments Corporation

The Uflex™ Automation Platform from Universal Instruments Corporation is a Pick-and-Place Machine that operates automatically with a working vision system. It can accommodate PCBs measuring from 50.0 x 75.0 x 0.5 mm to 630 x 508 x 12 mm, while the largest component size can be 127 x 127 x 100 mm. This machine has three heads for mobility, and the maximum number of feeders ranges from 0 to 10.

Download Brochure Product Details

Manual/Motorized PCB Depaneling Equipment

Depaneling Equipment from LPKF Laser & Electronics AG

The PicoLine 5440 from LPKF Laser & Electronics AG is a Manual/Motorized Depaneling Equipment for the PCB separation and packaging process. It can operate on a maximum working area of 533 x 610 x 11 mm, with a maximum board length of 355 mm. The PicoLine 5440 equipment is available in dimensions of 1660 x 1720 x 1900 mm, a net weight of 2000 kg, and works on a power supply of 400 VAC, 3-phase, 50 – 60 Hz.

Download Brochure Product Details

Sponsored by Digikey

Automated 3-axis Dispensing System with Contactless Linear Motor

Solder Paste Dispenser from Nordson Corporation

The PROX from Nordson Corporation is an Automated Dispensing System with a work area of 500 x 500 mm. It employs a contactless linear motor and offers improved actuation speed, fewer moving parts, and reduced maintenance needs due to significantly lower wear and tear. This 3-axis dispensing system is specifically designed and configured for precise fluid dispensing using EFD syringe barrel and valve systems.

Download Brochure Product Details

500 Gram Solder Paste Mixing Solution for Enhanced Productivity

Solder Paste Mixer from JAPAN UNIX

The UM-113 from Japan Unix is a Solder Paste Mixture with a working capacity of 500 grams. It uses centrifugal mixing at a rotating speed ranging from 100 to 1000 RPM to mix the paste. This solder paste mixer maximizes the potential of solder paste, enhancing productivity with its exclusive design. In just two minutes, it transforms solder paste into a printable condition while ensuring stable paste consistency.

Download Brochure Product Details

Advanced PCB Storage Solution: Multi Magazine Buffer Equipment

Buffer Equipment from EUNIL CO., LTD

The ESB-300-YL from EUNIL is an Advanced Buffer Equipment designed and manufactured to store PCBs during various production processes effectively. It has a capacity of 12 pieces, accommodating PCB sizes ranging from 50 x 50 mm to 430 x 350 mm. The machine is available in an enclosure that measures 1045 x 930 x 1600 mm.

Download Brochure Product Details

Solder Paste Inspection Machine for Board Dimensions up to 686 x 870 mm

Solder Paste Inspection Equipment from Saki Corporation

The 3Si-ZS2 from Saki Corporation is a Solder Paste Inspection Equipment. It can accommodate PCBs measuring up to 686 x 870 mm and features a camera system that uses 3D imaging to inspect solder joints. This system produces images with a resolution from 7 to 18 µm and a height resolution of 500 µm. The top and bottom clearance for easy mobility of the camera is 40 mm and 60 mm, respectively.

Download Brochure Product Details

BGA Rework Station for Board Dimensions up to 380 x 380 mm

Rework Station from 1Clicksmt.com

The PRO-650 from 1ClickSMT is a BGA Rework Station that can accommodate Printed Circuit Boards of size 380 x 380 mm. It supports component sizes ranging from 2 x 2 mm to 50 x 50 mm and uses V-shaped slots for PCB positioning. The upper and lower zones utilize hot air, while the bottom zone employs an infrared heater.

Download Brochure Product Details

About PCB Directory

PCB Directory is the largest directory of PCB Manufacturers and Fabricators on Internet. We have listed the leading Printed Circuit Board manufacturers around the world and made them searchable by their location and their capabilities.
