12 November, 2024 Newsletter - PCB Directory

Top stories this Month View it in your browser

Monthly Edition
Date: 12 November, 2024

Featured Products this Month

3D Solder Paste Inspection Equipment for PCB Dimensions of up to 510 x 460 mm

Solder Paste Inspection Equipment from Omron Corporation

The VP9000 High-speed Machine from Omron Corporation is a 3D Solder Paste Inspection (SPI) equipment that uses a phase shift method for post-SMT screen printing inspection. It uses a 360° ring light source that projects against inspection objects (solder paste) and performs three-dimensional measurements to achieve reliable inspections.

Download Brochure Product Details

Low-Voiding, No-Clean Solder Paste for BGA and BTC Soldering Applications

Solder Paste from AIM Metals & Alloys LP

The V9 from AIM Metals & Alloys is a No-Clean Solder Paste with SAC305 T4 alloy. It minimizes voiding, achieving void levels as low as 1% on BGAs and less than 5% on BTCs. This solder paste has a melting temperature of 217-220°C and supports a reflow temperature range of 230-260°C. It is compatible with all flux types and is suitable for BGA, BTC, and LED soldering applications.

Download Brochure Product Details

Automated Optical Inspection System for PCB Dimensions up to 690 mm x 610 mm

Automated Optical Inspection (AOI) Equipment from Koh Young America, Inc

The Zenith-M from Koh Young Technology is a 3D AOI Equipment that uses 3D Shadow Free Moiré Technology. It has a 4-megapixel high-speed camera with a field of view (FOV) of 47 mm x 35 mm. This AOI equipment has a resolution of 20 µm and an inspection speed of 25 cm²/sec. It can accommodate PCB sizes of up to 690 mm x 610 mm and PCB thicknesses from 0.4 to 5 mm.

Download Brochure Product Details

Reflow Soldering Equipment with Heating Zone Length of 2590 mm

Reflow Soldering Equipment from Europlacer

The TRA I-f82 from Europlacer is a Reflow Soldering Equipment with a heating zone length of 2590 mm. It has 8 heating zones (top and bottom) of length 310 mm each along with 2 cooling zones. It can accommodate PCB sizes ranging from 50 to 460 mm and has an adjustable conveyor, chain oiler, and start-stop function.

Download Brochure Product Details

Fume Extraction Equipment for PRE-GAS Volume Extraction

Fume Extraction Equipment from Metcal

The BVX-105 from Metcal is a single-user PRE-GAS Fume Extraction System that can be used directly on the workbench. It produces a fan capacity of 65 CFM and a flow rate of 50 CFM with the filter, delivering a suction force of 1250 Pa (5" WC). This equipment has an adapter that allows switching between plenum and arm extraction options.

Download Brochure Product Details

Halide-Free No-Clean Solder Flux for Wave and Spray Soldering

Solder Flux from MacDermid Alpha Electronics Solutions

The 985M from Kester is a Halide-free, No-clean Solder Flux tailored for wave soldering and touch-up applications. It has a solid content of 3.6% and is designed to work effectively with both traditional tin-lead and lead-free solder alloys. This solder flux improves soldering performance and helps reduce solder bridges, providing clean, non-corrosive, and tack-free residues that eliminate post-soldering cleaning.

Download Brochure Product Details

Sponsored by DigiKey

Flying Probe Tester for PCB Sizes from 50 x 50 mm to 610 x 510 mm

Flying Probe Tester from HIOKI E.E. Corp

The FA1816 from HIOKI E.E. Corp is a Horizontal Single-Sided Flying Probe Tester that has 2 probe arms. It has high-resolution cameras with high-power lenses (1x optical zoom) to deliver accurate probing of the board. This equipment also has optional 2x lenses to further improve alignment precision and proprietary probes that enable testing with shallower impacts and without compromising speed.

Download Brochure Product Details

UV Curing Machine with Microwave Activated UV Lamps

PCB Curing Oven from Specialty Coating Systems Inc

The PrecisionCure UVC (MUV) from Specialty Coating Systems is a UV Curing Machine that uses Heraeus Noblelight microwave-activated UV lamps for the curing process. These tubular mercury lamps deliver an output power of 300 W/in. and have a focused irradiator with a focal point of 2.1 inches below the irradiator unit.

Download Brochure Product Details

2D, 2.5D, 3D Slicing, and Planar CT X-ray Inspection System

X-ray Inspection System from Test Research, Inc

The TR7600TL SIII from Test Research, Inc. is an X-ray Inspection System that uses 2D, 2.5D, 3D Slicing, and Planar CT (Optional) inspection methods. It uses a microfocus X-ray tube as the X-Ray source with an excitation voltage of up to 130 kV and has 3 or 5 ultra-high-speed line-scan CCD cameras providing a resolution of 10, 15, 20, and 25 µm.

Download Brochure Product Details

3D Solder Paste Inspection Equipment for PCB Sizes of up to 51 x 51 cm

Solder Paste Inspection Equipment from ASC International, Inc

The AP500 from ASC International is a 3D Solder Paste Inspection (SPI) Equipment that uses Phase Shift Interferometry (PSI) for measurement. It has a camera with a resolution of 1280 x 1024 pixels, a lateral resolution of 1.78 µm, and a field of view of 8.7 x 6.2 mm. This SPI machine has a white LED for illumination and can generate inspection results in just one second.

Download Brochure Product Details

Benchtop Conformal Coating Machine with Flexible Three-Axis Robot

Conformal Coating Machine from Mycronic AB

The MYC10 from Mycronic AB is a Conformal Coating Machine that has a flexible three-axis robot designed for benchtop selective coating applications. It has optional tilting and rotating capabilities with flexible multi-axis control enabling coating even on complex PCB designs. It can handle PCB sizes of up to 320 x 400 mm with a clearance of 90 mm above and below the PCB.

Download Brochure Product Details

Reflow Soldering Equipment with Heating Zone Length of 5063.5 mm

Reflow Soldering Equipment from BTU International, Inc

The Aurora 200N from BTU International is a Reflow Soldering Equipment that has a heating zone length of 5063.5 mm. It has 16 heating zones (top and bottom each) and 11 cooling zones (6 top, 5 bottom). This reflow soldering equipment has a conveyor width of 620 mm and a conveyor speed from 254 to 2540 mm/min.

Download Brochure Product Details

About PCB Directory

PCB Directory is the largest directory of PCB Manufacturers and Fabricators on Internet. We have listed the leading Printed Circuit Board manufacturers around the world and made them searchable by their location and their capabilities.
