Latest News & White Papers this Week

19th December, 2023 Newsletter - PCB Directory

Top stories this week. View it in your browser

Monthly Edition
Date: 19th December, 2023

Sponsored by DigiKey

Take your design to the next LAYER!

Numerous parameters available. Dynamic configurator offers instant quoting and ordering options. Free shipping to US addresses! Click here to learn more.

New White Papers & Articles

What is a PCB Coating Thickness Gauge? - PCB Directory

11 Fundemental Design Rules for the Panelization of PCBs - LPKF Laser & Electronics AG

Improving The PCB Print Process Using Factory Data - Siemens

Controlling Electromagnetic Emissions From PCB Edges in Backplanes -Issue 01 - Lamsim Enterprises

ANZERs to Understanding Printed Circuit Board Assembly - ANZER

Latest Trends in Core Materials Supporting Next-Generation Semiconductor Packages and Substrate - Resonac Corporation

More Whitepapers

Upcoming Event

Smart Energy Week 2024

Date: Feb 28 - Mar 01 2024

Location: Tokyo Big Sight, Japan

More Events

New PCB Equipments

Automated Optical Inspection Machine for PCB Dimensions up to 508 x 457 mm

Automated Optical Inspection (AOI) Equipment from Machine Vision Products, Inc

The Versa LP15 from Machine Vision Products (MVP) is an Automated Optical Inspection Machine. It is designed for inspecting PCBs measuring up to 508 x 457 mm, while the average PCB thickness from 0.01 to 12.5 mm. This machine features a 12 megapixels camera that produces images with resolutions of 5 µm and 20 µm.

Download Brochure Product Details

Selective Soldering Equipment for PCB Dimensions up to 460 x 460 mm

Selective Soldering Machine from Hentec Industries, Inc. (RPS Automation)

The Vector 460 by Hentec Industries is a Selective Soldering Equipment that can accommodate PCB dimensions from 25 x 25 mm to 460 x 460 mm. It has a solder pot capacity of 15.9 Kg, while the flux tank can hold 1 litre. The heating time required to melt the solder is 60 minutes, after which it can attain temperatures up to 400°C using a PID temperature controller.

Download Brochure Product Details

Ultrafine No-Clean Solder Paste for Precision Electronics Assembly

Solder Paste from AIM Metals & Alloys LP

The NC259FPA from AIM Metals & Alloys is an Ultrafine Lead-free Solder Paste that is composed of an alloy of Tin (96.5%), Copper (0.5%), and Silver (3%). It uses a no-clean flux, which helps in ensuring a clean flux residue during the soldering process. This paste has an optimum melting point from 217°C to 220°C. It is designed for Type 6 and finer solder powders and ensures precise print definition and efficient transfer rates.

Download Brochure Product Details

UV Curing Machine with Integrated Selective Conformal Coating and Dispense System

PCB Curing Oven from Specialty Coating Systems Inc

The Precision UVC from Specialty Coating Systems is a PCB Curing Machine. It offers full-spectrum UV curing in integration with the SCS PrecisionCoat selective conformal coating and dispense system. Coupled together, components move from the PrecisionCoat to the Precision UVC automatically and the curing cycle is controlled by the coating system. The Precision UVC, when controlled by a computer, can also operate independently of a coating system.

Download Brochure Product Details

No-Clean, Ultra-Low Voiding Solder Paste

Solder Paste from MacDermid Alpha Electronics Solutions

The ALPHA OM-362 from MacDermid Alpha is a Lead-free Solder Paste that is composed of an alloy of Tin (96.5%), Copper (0.5%), and Silver (3%). It uses a no-clean flux, which helps in leaving a clean flux residue during the soldering process. This paste has an optimum melting point of 217°C. It achieves IPC Class III voiding on BGA components, maintaining an average voiding of less than 10% on Bottom Terminated Components (BTC).

Download Brochure Product Details

3D Solder Paste Inspection Equipment for PCB Dimensions up to 510 x 460 mm

Solder Paste Inspection Equipment from Omron Corporation

The VP9000 (Standard Machine) from Omron Corporation is a 3D Solder Paste Inspection Equipment. It can accommodate PBCs measuring from 50 x 50 mm to 510 x 460 mm with thickness varying from 0.3 to 5 mm. This machine uses the phase shift inspection method and features a camera system that produces image resolution of up to 5 µm with an inspection speed of up to 8900 mm2/sec.

Download Brochure Product Details

Sponsored by DigiKey

Conformal Coating Machine for PCB Dimensions up to 517 x 537 mm

Conformal Coating Machine from Nordson Corporation

The Select Coat SL-1040 from Nordson Corporation is a Conformal Coating Machine that can accommodate PCBs measuring up to 517.5 x 537.5 x 100 mm. It uses two sets of 2 and 3 valves each for selective conformal coating. The nozzle of this machine dispenses material with an air pressure of 620 kPa (90 psi. 6.2 Bar), up to 0.34 m3/min (12 SCFM) ¼-in. male NPT connection type.

Download Brochure Product Details

118,000 CPH Automated Pick and Place Machine

Pick and Place Machine from Mycronic AB

The MYPro A40DX from Mycronic AB is an Automated Pick and Place Machine. It supports component sizes from 01005 to 45 x 45 x 15 mm or as long as 150 x 40 x 15 mm. This machine employs high-speed MX7™ mounthead technology, which moves independently in theta and Z axes and can pick, rotate and place nearly any component with extreme precision.

Download Brochure Product Details

Automated Optical Inspection Machine from PCBs Measuring up to 510 x 460 mm

Automated Optical Inspection (AOI) Equipment from MEK Americas LLC

The ISO-Spector M2 from MEK Americas is an Automated Optical Inspection Machine. It is designed for inspecting PCBs measuring up to 510 x 460 mm, while the average component size and height can be 0402 metric and 25 mm respectively. This machine features a 25-megapixel camera with a field-of-view (FOV) of 69 x 69 mm.

Download Brochure Product Details

Automatic PCB Cleaning Machine with Cleaning Basket size of 470 x 470 mm

PCB Cleaning Machine from kolb Cleaning Technology GmbH

The AQUBE LH5 from Kolb Cleaning Technology is a PCB Cleaning Machine with a capacity of up to 176 eurocards per cycle and a cleaning basket measuring 470 x 470 mm. It is designed for process-safe fine cleaning of assembled PCBs, hybrids (HDIs, SiPs), and misprints, addressing reflow flux residues, resin, copper, oxide, and soldering support substances. This cleaning machine has a two-tank system with a triple-circuit system and ClosedLoop water reprocessing for efficiency.

Download Brochure Product Details

3D Solder Paste Inspection Equipment for PCB Dimensions up to 510 x 460 mm

Solder Paste Inspection Equipment from MEK Americas LLC

The PowerSpector S2 SPI from MEK Americas is a 3D Solder Paste Inspection Equipment. It can accommodate PCBs measuring up to 510 x 460 mm with thicknesses varying from 0.3 to 4 mm. This machine uses a multi-colour lighting system and features a camera system that uses a patented 5D sensor and high-grade telecentric lens. It can detect components as small as 01005 chip with an inspection speed of up to 9300 sq.

Download Brochure Product Details

PCB Laminate Meeting NASA’s Requirements for No Visible Bromine

PCB Laminates from Ventec International Group

The VT-901 from Ventec International Group is a PCB Laminate that is certified by Underwriters Laboratories. It has a base material of Polyimide with a layer of copper foil bonded to it, resulting in a thickness between 0.05 to 3 mm. This laminate has a thermal decomposition temperature (Td) of 395°C and a glass transition temperature of 250°C with a coefficient of thermal expansion from 11 to 12 ppm/°C on the XY axis and 50 to 150 ppm/°C on the Z axis.

Download Brochure Product Details

About PCB Directory

PCB Directory is the largest directory of PCB Manufacturers and Fabricators on the Internet. We have listed the leading Printed Circuit Board manufacturers around the world and made them searchable by their location and their capabilities.
