9th January, 2024 Newsletter - PCB Directory

Top stories this week. View it in your browser

Monthly Edition
Date: 9th January, 2024

Sponsored by DigiKey

Take your design to the next LAYER!

Numerous parameters available. Dynamic configurator offers instant quoting and ordering options. Free shipping to US addresses! Click here to learn more.

New White Papers & Articles

When to Request a Custom Reflow Profile - Advanced Assembly

Teardrops Improve Your PCB Quality and Yield - Altium Limited

Ten things that may be costing you - Siemens

High Tg Bromine-free Laminates for PWB Applications - Isola Group

Understanding Design for Manufacturing (DFM) Procedures in PCBs - PCB Directory

More Whitepapers

Upcoming Event

DesignCon 2024

Date: Jan 30-Feb 1, 2024

Location: Santa Clara Convention Center Santa Clara, CA

More Events

New PCB Equipments

In-Line Flying Probe Tester for PCB Dimensions up to 284 x 365 mm

Flying Probe Tester from Mycronic AB

The LM400 from Mycronic AB is an In-Line Flying Probe Tester with a double and quad-density grid test system. It supports a maximum board size of 284 x 365 mm and can accommodate PCBs measuring 8 mm in thickness. This tester offers double (70 mils) or quad (50 mils) electronic interface options with up to 49,152 test points (quad density 50 mils).

Download Brochure Product Details

X-Ray Inspection System with 225X Optical Magnification

X-ray Inspection System from Manncorp

The MX1 from MannCorp is an X-Ray Inspection System that is designed for real-time imaging of multilayer PCBs and dense metal BGAs, µBGAs, and chip scale packages. It features continuous optical zoom magnification from 4x to 100x geometric and 225x optical magnification along with a 15x geometric magnification when using variable angle viewing.

Download Brochure Product Details

Automated Optical Inspection System for PCB Dimension up to 750 x 500 mm

Automated Optical Inspection (AOI) Equipment from MEK Americas LLC

The VS60 Inline from MEK Americas is an Automated Optical Inspection (AOI) System that is designed for inspecting PCBs measuring up to 750 x 500 mm. It features a 60 megapixels camera to achieve an inspection speed of 5 sec per assembly. This system employs an overhead orthogonal camera and bundled LED lighting system to minimize influence of ambient light.

Download Brochure Product Details

Smart Nitrogen Dry Cabinet for Drying/Storing Moisture-Sensitive Devices

Dry Cabinet from EMT Electronics Engineering Limited

The XLC-N2 from EMT Electronics Engineering is a Dry Cabinet that is designed for drying and storing moisture-sensitive devices (MSDs). It has internal dimensions measuring 1197 x 1654 x 930 mm and has a total capacity of 1840 litres. This cabinet adheres to IPC/JEDEC J-STD 033C and IPC-1601 standards and allows moisture-sensitive materials and PCBs to be stored for an unlimited period of time.

Download Brochure Product Details

Dual-Directional Gate Conveyor for PCB Dimension up to 360 x 460 mm

PCB Conveyor from IPTE Factory Automation n.v.

The Manual Gate Unit (MGU) from IPTE Factory Automation is Gate Conveyor. It is available with either left-to-right or right-to-left direction (to be specified at the time of order) depending on the application. This conveyor moves at an adjustable speed between 100 to 700 mm/sec and has a width of 800 mm with a height between 930 to 1000 mm.

Download Brochure Product Details

Selective Soldering Equipment for PCB Dimensions up to 356 x 457 mm

Selective Soldering Machine from Hentec Industries, Inc. (RPS Automation)

The Vector 300 from Hentec Industries is a Selective Soldering Equipment that can accommodate PCB dimensions from 25 x 25 mm to 356 x 457 mm. It has a solder pot capacity of 15.9 Kg, while the flux tank has a capacity of 1 litre. The heating time required to melt the solder is 60 minutes, after which it can attain temperatures up to 400°C, using a PID temperature controller.

Download Brochure Product Details

Ultraviolet Light Curing System for Precision PCB Surface Bonding

PCB Curing Oven from PVA Global

The Spectra from PVA Global is an Ultraviolet Light Curing System. It utilizes Fusion® UV lamps by Heraeus to initiate fast ultraviolet light polymerization of adhesives and coatings in an efficient inline process. This system can accommodate PCBs ranging from 50 to 500 mm in dimension and measuring from 51 to 152.4 mm in height.

Download Brochure Product Details

Sponsored by DigiKey

Selective Soldering Machine for PCB Sizes up to 457 x 610 mm

Selective Soldering Machine from Pillarhouse International Ltd

The ORISSA SYNCHRODEX from Pillar House International is a Selective Soldering Machine that can accommodate PCBs measuring up to 457 x 610 mm. It has a solder pot capacity of 15 kg, and the flux tank can hold up to 1 litre of flux. A conveyor with an edge clearance of 3 mm is used to transport the PCBs, while flux is applied to these PCBs in 50 seconds.

Download Brochure Product Details

Automated X-Ray Inspection Machine for PCB Dimensions up to 2100 x 510 mm

X-ray Inspection System from Test Research, Inc

The TR7600F2D QL from Test Research, Inc (TRI) is an Automated X-Ray Inspection (AXI) Machine. It has a flat panel detector and uses a 2D inspection method to produce images with a resolution between 5 to 25 µm. This AXI system can accommodate a maximum PCB size of 2100 x 510 mm, measuring up to 7 mm in thickness and weighing up to 12 kg.

Download Brochure Product Details

PCB Flipper and Inverter for Efficient SMT Production Line Operation

PCB Flipper and Inverter from Hayawin Electronic Technology Co.,Ltd

The YS-LCV460 from Hayawin Electronic Technology is a PCB Flipper and Inverter that can efficiently turn PCBs 180° on SMT production lines. It has a quick cycle time of less than 12 seconds and can accommodate PCBs measuring up to 5530 x 460 mm. This PCB flipper employs a dual-directional conveyor, allowing operation from Left to Right, and Right to Left with a conveyor height from 920 to 980 mm.

Download Brochure Product Details
