New PCB Equipments

Automated Optical Inspection Machine for PCBs Measuring 320 x 300 mm

Automated Optical Inspection (AOI) Equipment from MEK Americas LLC

The i22XDA-300 from MEK Americas LLC can inspect PCBs of size 320 x 300 mm. It features a 5-megapixel camera with a 36 x 30 mm (FOV) and an image resolution of 15 µm. The top clearance for the camera is 40 mm, and an inspection speed of 600 mm/s. This AOI can use three different types of lighting settings including DL type Lighting or ML type Lighting/UV type Lighting/White Lighting. The relative humidity in the machine can be set in a range of 20 - 90% RH.

Download Brochure Product Details

Selective Soldering Equipment for PCB Dimension up to 660 x 711 mm

Selective Soldering Machine from Hentec Industries, Inc. (RPS Automation)

The VECTOR 600 by Hentec Industries accommodates PCB sizes from 25 x 25 mm to 660 x 711 mm. It has a 15.9kg solder pot, and 1-liter flux tank, and reaches 400°C in 60 minutes using PID control. The conveyor moves PCBs at 0.127 m/sec in a 609 x 609 mm soldering area. The spray fluxer's diameter ranges from 6 to 20 mm, and the solder wave height can reach 6 mm. N2 gas, used for solder heating, is exhausted via a nozzle of 1.5 to 20 mm diameter at 5.5 bar pressure.

Download Brochure Product Details

Precision Automated Depanelizing for Efficient Electronic Assembly

Depaneling Equipment from Asys Group Americas Inc

The DIVISIO 6000 from Asys Group Americas is an Automated Depanelizing Equipment. It supports PCBs measuring 20 to 460 mm in length, 0.8 to 5 mm in thickness, and a maximum component height of 40 mm. This equipment has two carbon axes in parallel and achieves a cycle time of under 2.5 seconds per circuit.

Download Brochure Product Details

Selective Coating/Dispensing System with 3-Axis Motion Platform

Conformal Coating Machine from PVA Global

The DELTA 8 from PVA Global uses one valve for selective conformal coating with a working area of 621 x 595 x 100 mm. The nozzle dispenses at a rate of 670 mm/sec with an air pressure of 90 psi. It employs a conveyor with an average width between 50 to 500 mm, and a conveyor height from 940 to 965 mm. The conveyor can move at a speed of up to 24.4 m/min and has an edge clearance of 4.7 mm.

Download Brochure Product Details

Populated Board Testing System with Work Area of 510 x 460 mm

Flying Probe Tester from HIOKI E.E. Corp

The FA1240-61 from HIOKI has a probe work area of 510 x 460 mm. It has an independent 4-arm movement and up to 40,000 test steps with a measurement speed of 0.025 sec./step. This tester uses an automated conveyor with a speed of up to 40 meters/min and can transport a mass of up to 2 kg. It is ideal for verifying correct mounting on populated boards and ensures global standards compliance.

Download Brochure Product Details

Precision Reflow Soldering Equipment for Void-Free Production

Reflow Soldering Equipment from Kurtz Ersa

The EXOS 10/26 from Kurtz Ersa is a Reflow Soldering Equipment with 11 heating zones, 4 cooling zones, and a vacuum chamber after the peak zone. It is divided into 4 parts (infeed, preheating, peak, vacuum, and cooling zone), each of which has its conveyor. This equipment has perfect synchronization of the assemblies and transitions by utilizing a sensor-monitored conveyor and requires no external infeed module.

Download Brochure Product Details

4MILL300ATC: Precision PCB Prototyping with P2J Technology, s.r.o.

PCB Prototyping Equipment from P2J Technology, s.r.o.

The Mipec 4MILL300ATC from P2J Technology is a PCB Prototyping Instrument that can support PCB dimensions of up to 200 x 140 mm. It has a spindle speed of 60,000 rpm and a fully automated tool-change system. It has a working area of 240 x 180 x 30 mm and a drilling speed of up to 120 strokes/min. It has a resolution of 1µm. It is available in an enclosure that measures 420 x 455 x 435 mm and requires an AC supply of 115/230V, 50-60Hz.

Download Brochure Product Details

Sponsored by DigiKey

PCB Transfer Conveyor with Working Width from 50 to 500 mm

PCB Conveyor from PVA Global

The Queue from PVA Global has an adjustable speed between 0.15 to 24 m/min, supports a maximum pallet weight of 10 lbs/4.5 Kg, and can be used to transport bare board assemblies or pallet fixtures. It has a conveyor height of 890 to 965 mm and an adjustable working width between 50 to 500 mm. This transfer conveyor has a component clearance of 100 mm (top and bottom) and 4.75 mm (edge).

Download Brochure Product Details

RoHS-Compatible Water-Soluble Tin, Silver and Copper Solder Paste

Solder Paste from MacDermid Alpha Electronics Solutions

The ALPHA WS-698CPS from MacDermid Alpha Electronics Solutions is a RoHS-compatible Water-Soluble Solder Paste with Tin (96.5%), Silver (3%), and Copper (0.5%). It melts between 217 to 225°C, available in Type 4 and Type 6 variants. It maximizes reflow yield for lead-free processing, achieving full alloy coalescence at 0.25 mm (0.010”) with 0.100 mm (4miL) stencil thickness, minimizing rework.

Download Brochure Product Details

Solder Paste Inspection Precision for PCB Dimensions up to 280 x 300 mm

Solder Paste Inspection Equipment from MIRTEC

The MS-11em from MIRTEC is a Solder Paste Inspection Equipment. It utilizes a 25 MP camera system that produces images with a resolution of 7.7 or 10 µm and a height resolution of ±1 µm. It can accommodate PCBs weighing up to 4 Kgs and measuring from 50 x 50 mm to 280 x 330 mm. The minimum edge clearance of the camera is 3 mm, and the bottom clearance is 50 mm.

Download Brochure Product Details

Automated Optical Inspection Machine for PCBs Measuring 510 x 460 mm

Automated Optical Inspection (AOI) Equipment from Test Research, Inc

The TR7700QH SII from Test Research, Inc. handles PCBs up to 510 x 510 mm, with thicknesses from 0.6 to 5 mm and weights up to 5 Kg. It features a 21-megapixel camera for high-resolution imaging (15 µm) and operates at 80 cm²/sec inspection speed. The equipment includes a dual-directional conveyor with adjustable height (880 to 920 mm) and is enclosed within dimensions of 1100 x 1730 x 1700 mm.

Download Brochure Product Details

UV Curing Oven for Precision PCB Surface Bonding

PCB Curing Oven from Anda Automation

The UV-2 by Anda Automation has a 620 mm curing zone, it accommodates PCBs from 50 mm to 460 mm. It features a unidirectional conveyor with adjustable height (900 ± 20 mm) and variable speed (0.5 to 5 m/min). Standard features include a PLC controller and touchscreen interface. Enclosed with dimensions of 1500 x 1137 x 1460 mm, it operates on a 380 V (3-phase) AC supply.
