28 July, 2022 Newsletter - PCB Directory

Top stories this week. View it in your browser


Monthly Edition
Date: 28 July, 2022

Sponsored by Digi-Key


Latest PCB News
News
PCEA Announces Dates for the PCB EAST 2023 Tradeshow in May

PCEA
News
Atotech Inaugurates its Manufacturing Plant in Mexico and Starts Production

Atotech
News
Indium Partners with SAFI-Tech to Develop Supercooled Solder Materials

Indium Corporation
News
Ventec Invests in New Prepreg Machines to Expand its Global Manufacturing Capability

Ventec International Group
News
Atotech Joins Consortium to Develop First Ever Made-in-Germany Quantum Computer

Atotech
News
IPC Reports Low Economic Growth of Electronics Market in USA and Europe

IPC
News
Researchers Develop New Material with 150% Better Heat Conduction Efficiency

UC Berkeley
News
Electrolube's High-Performance FPC Coating Receives UL94V-0 Approval

MacDermid Alpha Electronics
News
ClassOne to Showcase its New High-Sensitivity Particle Inspection System at SEMICON West 2022

ClassOne
News
CyberOptics Wins 2022 EM Innovation Award for its Multi-Function System for AOI, SPI, and CMM

CyberOptics Corporation
Interesting White Papers & Articles
Reasons for Leaning Out Your PCBA and Electronics Assembly - Caltronics
PCB Manufacturing Production and Process - Altium
Characterization of PCB Plated-Thru-Hole Reliability using Statistical Analysis - Isola Group
Flexible Substrates for Smart Sensor Applications - Dyconex
Portability is key to competitiveness for PCB manufacturers - Siemens
Influencing Factors on Shielding Effectiveness of Board Level Shields - Laird
More Whitepapers
Sponsored by Digi-Key
Digi-Key
DKRed: A premium PCB service from Digi-Key
Dynamic configurator offers instant quoting and ordering options. Prices start at $1.50 per square inch, low minimum order quantity of only 4 boards with a 10 day turn around. Free shipping to USA addresses! Click here to learn more.
New PCB Equipment
X-ray Inspection System
Automated X-ray CT Inspection System for Mass-Production
X-ray Inspection System  from Omron Corporation

The VT-X900 from Omron Corporation an Automated X-ray CT Inspection System. It has an imaging resolution of up to 3 µm and a maximum inspection area of 330 x 330 mm. This inspection system ensures process quality in a mass-production environment by using Submicron CT imaging with a variety of Metrology data.
Download Brochure Product Details
Loader/Unloader
Auto PCB Unloader
Loader/Unloader  from GENITEC Technology

The GAM620A from GENITEC Technology is an Auto Unloader that supports PCB sizes of 350 x 300 mm. It has a tray size of up to 280 x 370 mm and has a tray stacking height of 400 mm. This machine can automatically unload PCBAs in tray after the cutting process of in-line separator GAM320AT/330AT. It has an unloading direction from left to right and has a maximum transferring speed of 800 mm/min.
Download Brochure Product Details
Buffer Equipment
Automatic PCB Buffer Stocker
Buffer Equipment  from Seamark

The SPL-350 from Seamark is an Automatic PCB Buffer Stocker that supports PCB sizes from 70 x 70 mm to 450 x 350 mm. It has a modular standalone design and can be connected to PCB conveyers, PCB loaders and SMT machines via SMEMA interface. This buffer stocker has a PLC control system and includes an easy-to-use touch screen control interface. It is available in an enclosure that measures 500 x 900 x 1200 m and requires an AC supply.
Download Brochure Product Details
Solder Paste Inspection Equipment
3D Solder Paste Inspection (SPI) Machine for PCBs
Solder Paste Inspection Equipment  from Vi TECHNOLOGY

The PI PRIMO XL from Vi TECHNOLOGY is a 3D Solder Paste Inspection (SPI) Machine that supports PCBs from 50 x 50 mm to 762 x 533 mm. In addition to paste inspection, it also offers simultaneous glue dot inspection. This machine uses PI’s patented Z-referencing technology which provides unprecedented accuracy to paste volume measurement. PI is designed to operate solely with a touch screen icon-based interface with no keyboard and no mouse.
Download Brochure Product Details
Pick and Place Machine
Pick & Place System for PCBs
Pick and Place Machine  from Essemtec USA, Ltd

The FOX2 from Essemtec USA is a Pick & Place System that supports PCB sizes of up to 406 x 305 mm. It supports a PCB thickness from 0.5 to 5.0 mm and a maximum component height of 18 mm (25 mm option also available). This machine has a placement speed of 12,000 cph and a dispensing speed of up to 100,000 dots/h. It is available in an enclosure that measures 880 x 1090 mm and requires an AC supply.
Download Brochure Product Details
Sponsored by Digi-Key


Rework Station
Rework Station for PCBs
Rework Station  from Kurtz Ersa

The HR 550 XL from Kurtz Ersa is a Rework Station that supports PCB dimensions up to 530 x 610 mm. It uses high-resolution cameras for placement and process monitoring with computer-aided component alignment. This semi-automatic unit has eight bottom radiator heating zones and motorized X/Y fine adjustment and component rotation. It is suitable for industrial and power electronics as well as large-format boards and is particularly attractive for service providers.
Download Brochure Product Details
Reflow Soldering Equipment
8-Zone Reflow Oven for Printed Circuit Boards
Reflow Soldering Equipment  from Oubel Group

The HS-0802-LF from Reflow Oven that supports PCB width of up to 400 mm. It has 8 heating zones which are 3500 mm in length and a heating time of 20 minutes. The conveyer direction is from right to left and has a speed from 0 to 2000 mm/min. It is available in an enclosure that measures 5400 x 1370 x 1555 mm and requires an AC supply.
Download Brochure Product Details
Dry Cabinet
Modular Dry Cabinets for PCBs
Dry Cabinet  from Bergen Group

The C1-1490-6 from Bergen Group is a Dry Cabinet that designed to protect the components from humidity range from 1%RH to 50%RH. It has a modular design with the main modules being display controller, power box, dehumidifier, shelf, caster wheel. The performance of the dry cabinet can be upgraded by just changing the modules. It has 5 shelves, and the interior environment is controlled by precise digital controller.
Download Brochure Product Details
Upcoming Event
Event Image
Ceramics Expo
Date: Aug 29 - 31, 2022
Location: Cleveland, Ohio
