Latest PCB News & Equipment

25 Aug, 2022 Newsletter - PCB Directory

Top stories this month. View it in your browser

Monthly Edition
Date: 25 Aug, 2022

Sponsored by Digi-Key

DKRed: A premium PCB service from Digi-Key

Dynamic configurator offers instant quoting and ordering options. Prices start at $1.50 per square inch, low minimum order quantity of only 4 boards with a 10 day turn around. Free shipping to USA addresses! Click here to learn more.

Interesting White Papers & Articles

New Approaches to Develop a Scalable 3D IC Assembly Method - Invensas

The impact of smart factory solutions on PCB manufacturing - Omron Corporation

Thermally Optimizing a High-Power PCB - Cadence Design Systems, Inc

IPC-CC-830B Versus the 'Real World' - Electrolube

What is Kelvin Test? - Gardien Services

Flexible Substrates for Smart Sensor Applications - Cadence Design Systems

More Whitepapers

New PCB Equipment

Automated Pick and Place Machine with Vision Centering

Pick and Place Machine from DDM Novastar Inc

The LS40V from DDM Novastar is an Automated Pick and Place Machine with vision centering that supports PCB sizes up to 343 x 560 mm. It offers technologically advanced features with 56 single feeder positions (up to 84 feeders using bank feeders) where quick setup, ease of operation and high reliability are paramount. This machine has a placement rate of up to 4800 cph with an accuracy of ± 0.001 inches (0.025 mm).

Download Brochure Product Details

Lead-Free Nitrogen Wave Soldering Machine

Wave Soldering Equipment from I.C.T Intercontinental

The Acrab 350 from I.C.T Intercontinental is a Lead-Free Nitrogen Wave Soldering Machine that supports PCB widths from 50 to 350 mm. This high-stability machine provides unparalleled heating performance and temperature control system that meet the requirements of various welding processes. It has a unique energy saving design to reduce the using cost for customers and has a sealing structure design to prevent flux pollution.

Download Brochure Product Details

Extra Soft, Slow Rebound Polyurethane Foam

PCB Laminates from Rogers Corporation

The PORON® 4790-92 from Rogers Corporation is an extra soft, slow rebound Polyurethane Foam. It provides excellent protection for lower energy impacts and is conformable yet returns to its original shape, allowing for long-term performance. This foam has a thickness from 0.53 to 12.7 mm (0.021 to .5 in.) and a density from 144 to 480 kg/m3 (9 to 30lb/ft3).

Download Brochure Product Details

Conformal Coating Machine for PCBs up to 460 mm

Conformal Coating Machine from Oubel Group

The OB-GC450 from Oubel Group is a Conformal Coating Machine that supports PCB lengths up to 460 mm. It has a PCB conveyor height of 900 mm and a conveyor speed of up to 2400 mm/min. This machine has a high-speed, stable and reliable driving and control system. It has a patented fully-sealed module which can isolate fog corrosion of screw rod and slide rail.

Download Brochure Product Details

Automatic Vacuum PCB Stacker/ De-stacker for PCBs up to 500 x 500 mm

PCB Stacker and Destacker from SunzonTech

The VL-500W-SZ from SunzonTech is an Automatic Vacuum PCB Stacker/ De-stacker for board sizes up to 500 x 500 mm. It is designed for PCB production on SMT production line. This machine uses a Panasonic PLC control to provide smart control and includes a true color touch screen control panel for easy operation.

Download Brochure Product Details

Sponsored by Digi-Key

Ceramic-Filled Polyimide Prepreg High-Temperature Applications

PCB Laminates from Arlon EMD

The 84N from Arlon Electronic Materials is a Ceramic-Filled Polyimide Prepreg that is based on Arlon’s 85N pure polyimide system. It is designed for use in filling etched areas in polyimide multilayers that contain thick copper layers and for filling clearance holes in metal cores. The ceramic filler in the resin serves to reduce shrinkage and inhibit crack formulation during through-hole drilling in filled clearance areas.

Download Brochure Product Details

No Flow/Low Flow FR4.0 Prepreg Material for Harsh Environments

PCB Laminates from Ventec International Group

The Flex-Rigid VT-462(L) from Ventec is a No Flow/Low Flow FR4.0 Prepreg Material designed for applications requiring critical thermal management in the harshest environments. This IPC-4101E-compliant material is suitable for critical industries such as high-reliability military, aerospace/space, and other ultra-high reliability applications. It offers high Tg (175°C), high Td (360°C), and a low Dk of 3.8.

Download Brochure Product Details

No-Clean, Halogen-Free Solder Paste for Long-Term Jetting

Solder Paste from Indium Corporation

The PicoShot® NC-5M from Indium Corporation is a Solder Paste specifically formulated to be compatible with Mycronic jetting systems. It is a no-clean, halogen-free material that is chemically-compatible with Indium8.9HF Solder Paste and is optimized for long-term jetting. This solder paste provides exceptional jetting performance, and its unique oxidation barrier promotes complete powder coalescence during reflow to eliminate graping and similar reflow issues.

Download Brochure Product Details

Selective Soldering Machine for PCB Sizes up to 510 x 460 mm

Selective Soldering Machine from Juki Americas

The iCube from Juki Americas is a Selective Soldering Machine that supports PCB sizes from 80 x 50 mm to 510 x 460 mm. It has a unique heavy duty topside board clamping system ensures stability of PCB during soldering. This machine enables live viewing of the soldering to assist in the process setup and continuous monitoring throughout the process. Both video and still images can be acquired from the software for archiving.

Download Brochure Product Details

Lead-Free, No-Clean Solder Paste with High Electrochemical Reliability

Solder Paste from MacDermid Alpha Electronics Solutions

The ALPHA CVP-390V from MacDermid Alpha Electronics Solutions is lead-free, no-clean Solder Paste designed to maximize flexibility in manufacturing. It provides excellent electrochemical reliability in harsh operating conditions and delivers consistent print and reflow performance across a wide range of component types. This solder paste has a wide process window and exhibits more than 2.0 Cpk transfer efficiency between 60 to 120% at area ratios above 0.60 for maximum process flexibility.

Download Brochure Product Details

About PCB Directory

PCB Directory is the largest directory of PCB Manufacturers and Fabricators on Internet. We have listed the leading Printed Circuit Board manufacturers around the world and made them searchable by their location and their capabilities.
