With the resources of a strong network and the expertise of our team members, San Francisco Circuits provides you with a unique one stop solution to all your printed circuit needs, including PCB design, PCB manufacturing and PCB assembly.

 PCB Fabrication Capabilities

Get PCB Fabrication Quote from

San Francisco Circuits, Inc

  X

PCB Assembly Capabilities

Board Type

  • Flexible
  • Rigid
  • Hybrid
  • HDI
  • Rigid-Flex

Assembly Type

PCB Sides

  • Single Sided
  • Double Sided
Get PCB Assembly Quote from

San Francisco Circuits, Inc

Coating

Conformal Coating

Fine Pitch

0.3 mm

BGA Pitch

0.4 mm

Testing

Soldering Type

  • Hand Soldering
  • Leaded Solder
  • Lead-Free (RoHS)
  • Wave Soldering
  • Reflow Soldering
  • Robotic Soldering
  • Selective Soldering
  • Tin-lead Solder

Package Type

  • BGA
  • BGS
  • BTC
  • CBGA
  • CCGA
  • CCM
  • CGA
  • CLCC
  • COB
  • COF
  • CSP
  • CSPs
  • DFA
  • DFN
  • DIP
  • DSBGA
  • DSP
  • FFPGA
  • Flip Chip
  • Flip Chip SOIC
  • Flip-Chip
  • FPGA
  • GSP
  • IC
  • LCC
  • LCCs
  • LGA
  • LIDS
  • MBEA
  • MBGA
  • MCM
  • MELF
  • MEM
  • Micro-BGA
  • Mictor Connectors
  • MLF
  • MLP
  • MSOPS
  • Odd Form
  • PBGA
  • PLCC
  • POP
  • PQFN
  • QCG
  • QEP
  • QFN
  • QFP
  • QPF
  • QPN
  • SOD
  • SOIC
  • SOJ
  • SON
  • SOP
  • SOT
  • SSOP
  • TBGA
  • TQFP
  • TSOP
  • TSSOP
  • VFBGA
  • VGA
  • WLCSP
  • XFP

File Format

  • Ascii CAD
  • CAD
  • Centroid
  • DXF
  • Gerber
  • ODB ++
  • Orcad
  • Pulsonix

PCB Design Capabilities

Design Services

  • PCB Layout and Design
  • Schematic Entry
  • Panel Design for Manufacturing
  • Other

Design Software

  • PROTEL (Altium)
  • PADS Power PCB
  • ORCAD
  • WG
  • Cadence Allegro
  • Eagle
  • Kicad
  • EasyEda
  • PCBWeb Designer
  • ZenitPCB
  • TinyCAD
  • Osmond PCB
  • ExpressPCB
  • gEDA
  • Fritzing
  • Pad2Pad
  • DesignSpark
Get PCB Design Quote from

San Francisco Circuits, Inc

PCB Stencil Capabilities

Stencil Type

  • Framework
  • Non-Framework

Fiducials

  • Half Lasered on Board Side
  • Half Lasered on Squeegee Side
Get PCB Stencil Quote from

San Francisco Circuits, Inc

Stencil Type

PCB Repair / Rework Services

  • Circuitry & Pad Damage Repair
  • BGA Rework
  • Trace repair
  • Component repair
  • Pad & Track Repair
  • Solder Mask Repair
  • BGA Reballing
  • BGA Pad Demage Repair
  • Pad-on-Via Repair
  • Gold Plating Rework
Get PCB Repair / Rework Quote from

San Francisco Circuits, Inc

Capabilites

General
Number of Layers1 - 12
Board MaterialsFR4, FR406, IS410, Kapton, Shin-Etsu - Epoxy, Rogers - Epoxy, Dupont FR - FR Acrylic, Dupont LF - LF Acrylic, Adhesiveless Base Materials
Maximum Board Size16
Copper Thickness0.5 oz - 3 oz
Hole Aspect Ratio7:1
Minimum Hole Size0.008
Minimum Trace/Space0.006
Minimum Drill-to-Copper0.010
Minimum Pitch1 mm
Final FinishHASL (Solder), Lead Free Solder, Copper, Gold, Gold Fingers, White Tin, OSP
Solder MaskGreen, Black, Red, Blue, Yellow, White, Clear
CoverlayFR Coverlay, LF Coverlay, Shin-Etsu, Flexible Soldermask
Silk ScreenWhite, Black, Yellow
PCB FabricationScoring, Route & Retain
Additional FeaturesPlated Slots, Non-plated Slots, Controlled Dielectric, Covered Vias, Counter Sinks, Counter Bores, Dual Access Flex, Suspended Leads
Quality StandardsIPC 6012 Class 2, Electrical Testing, 100% Netlist Testing, TDR Testing
Minimum Board Thickness
2 layer0.010
4 layer0.020
6 layer0.020
8 layer0.062
10 layer0.062
12 layer0.062
Maximum Board Thickness
2 layer0.125
3-12 layer0.200
General
Number of Layers14 - 40
Board MaterialAluminum Core
Arlon
CEM
Copper Core
FR408
Getek
Nelco 4000
Rogers 3000
Rogers 4000
Rogers 5000
Taconic TLY
Polyimide
Maximum Board Size10
Copper Thickness4 oz - 6 oz
Hole Aspect Ratio15:1
Minimum Hole Size0.006
Minimum Trace/Space0.003
Minimum Drill-to-Copper0.003
Minimum Pitch0.3 mm
Final FinishHASL, Gold (ENIG/Hard/Soft), Selective Gold, Immersion Silver, OSP, White Tin
Solder MaskGreen, Black, Red, Blue, Yellow, White, Clear, Mix-and-match, Wet Mask, Dry Film
Silk ScreenWhite, Black, Yellow, Green, Red, Blue
PCB FabricationJump Scoring, Route & Retain, Milling
Additional FeaturesPlated Edges, Plated Milling, Plated Counter Bores & Counter Sinks, Edge Castellation, Controlled Impedance, Silver Filled Vias, Non-Conductive Filled Vias
Quality StandardsMilspec 31032, Milspec 55110, Milspec 50884, IPC 6012 Class 3, 100% Netlist Testing, TDR Testing
Minimum Board Thickness
2 layer0.005
4 layer0.010
6 layer0.031
8 layer0.040
Maximum Board Thickness
14-40 layers0.250
